供應
MLCC貼片陶瓷積層電容 Chip Capacitor
華新、國巨、風華、三星等
General purpose

Dielectric: NP0, X7R, Y5V
Size: 01005,0201,0402,0603,0805,1206,1210,1812
Capacitance: 0.5pF~0.82uF
Rated voltage: 10V, 16V, 25V, 50, 100V
High capacitance
Dielectric: X7R, X5R, Y5V
Capacitance: 1uF~100uF

.........................................................................................................................................................................................
Low profile (TT series)
Dielectric: X5R, Y5V
Rated voltage: 6.3V, 10V, 16V
Ultra-small size
Dielectric: NP0, X7R, X5R, Y5V
Size: 0201
Capacitance: 0.5pF~0.1uF
Rated voltage: 6.3V, 10V, 16V, 25V

.........................................................................................................................................................................................
Middle & high voltage
Dielectric: NP0, X7R, Y5V
Rated voltage: 200V, 250V, 500V, 630V
1kV, 2kV, 3kV
Safety certificated X2/Y3 (S3 series)
Dielectric: NP0, X7R
Size: 1808, 1812
Rated voltage: 250Vac

.........................................................................................................................................................................................
Safety certificated X1/Y2 (S2 series)
Dielectric: NP0
Size: 1808, 1812
Rated voltage: 250Vac
High Q & low ESR (HH series)
Dielectric: NP0
Size: 0402, 0603
Capacitance: 0.5pF~3300pF
Rated voltage: 16V, 25V, 50V

.........................................................................................................................................................................................
Microwave (MW series)
Dielectric: NP0
Size: 0402, 0603
Capacitance: 0.5pF~22pF
Rated voltage: 50V
Open-mode design (OP series)
Dielectric: X7R
Rated voltage: 100V, 200V, 250V, 500V

.........................................................................................................................................................................................
Capacitor arrays
Dielectric: NP0, X7R, Y5V
Size: 0603x4
Capacitance: 10pF~0.1uF
Rated voltage:
Low inductance
Dielectric: X7R
Size: 0612
Capacitance: 0.01uF~0.15uF
Rated voltage: 50V
