直流系統電源 Agilent 6632B

廠家: 美國安捷倫
尺寸: 43×9×37cm
重量: 13kg
市場價: US$ 2,531美元(未稅)

6632B 100 Watt System Power Supply, 20V, 5A

6630系列 性能指標pdf

• 輸出電壓范圍: 0 to 20 V
  輸出電流范圍: 0 to 5 A
• 編程精度
  Voltage: 10 mV
  + Current: 0.05% + 2 mA
  紋波與噪聲 (20 Hz to 20 MHz, with outputs ungrounded or with either terminal grounded)
  Voltage Normal Mode rms: 0.3 mV
  Voltage Normal Mode peak-to-peak: 3 mV
  Fast mode rms/ peak-to-peak: 1 mV/ 10 mV
  Current rms: 2 mA
• 負載與源效應
  Load Voltage: 2 mv
  Load Current: 1 mA
  Line Voltage: 0.5 mV
  Line Current: 0.5 mA
